•Using Single Chip Micro Computer(MCU) controller. The delay time is programmable & more precise reliably.

•8 channels and 20KW Power supply. Each channel has of independent EMI-Power Filter , CE certificate approved.

•Using Triphase 5-pin professional socket, Diphase & Triphase are compatible.

•Every output channel can be turned off immediately .

•Password function.

•Link In & Link Out function .

•Overload Voltage Alarm function: It alarms whenever the voltage is out of the range which you setup.

•Multi-sockets meet your different plugs

1) 额定输出电压：交流220V,50Hz
2) 额定输出电流：30A
3) 可控制电源：8路
4) 每路动作延时时间：19秒
5) 供电电源：VAC 50 / 60Hz 25A
6) 每路输出带指示灯
7) 锁匙开关控制电源
8) 单路额定输出电源：16A

型号:P308

电压:220 v(±20%)

电源频率:50赫兹或60赫兹(±5%

保护:过载电流保护和保护

电压表:空载精度±1%,满-载荷精度±1%

测序通道:8对序列的独立渠道控制。

功率输出:16A

时间序列:可编程的

单行开关:用单行开关,可以turgently任何通道

电压设置错误:5%

过载电压精度:±1%的无载准确性,满载的±1%的精度

接地电阻:R≤100 mΩ

单位的高度:2 u

产品尺寸(WXDXH):482x400x88mm

净重:10.25公斤

包装尺寸(WXDXH):607×183×524毫米

毛重:11公斤
